This tester is used for the verification test of the degree of protection to the risk of water penetration provided by the wrapper of equipment in fulfillment of IPX5 according to the IEC 60529.
Item |
IPX5 |
Water supply |
Water flow rate >12.5L/min±5% clean water witho ut inclusion. |
The nozzle diameter |
6.3 mm |
Water flow |
12.5 L/min |
Testing time |
Not less than 1min/m2 (not less than 3 mins) |
The distance from jet nozzle to enclosure |
2.5~3m |
Pressure Gauge |
0 - 0.25 MPa |
Reference standards |
IEC60529,IEC60598-1,IEC60335-1,IEC60745-1 |
Nozzle Material |
Stainless Steel |
Figure 6 - Test device to verify protection against water jests (hose nozzle)
Company introduction
HK LEE HING INDUSTRY CO., LIMITED are specialized in manufacturing special, custom built, test and measuring equipment for products testing as per international norms and offering calibration services andrelated information. Our products and services are used by research & development establishments, test laboratories, defense establishments, government institutions & manufacturing industries to fulfill the clients' requirements.
Main Products: Go No Go Gauges, IP Tester, Test Probe Kit, Impact Test Equipment, Test Probes, Spring Hammer, IEC 61032 Test Finger, AC Hipot Tester, IEC Test Probe, UL Test Probe, Material Flammability Tester, IP Code Tester, Impact Test Apparatus, Plugs and Socket Outlet Gauge, Security Testing Machine, Lamp Cap Gauge Tester, Lampholders Gauge Tester, Plug & Socket Tester, Electrical Safety Tester, LED Test Instruments, Environmental Test Equipment, Instrument Accessories, Weighing Sensor and More.
If you require equipment to test products such as home appliances, electrical accessories like switches, sockets, connectors, etc. industrial & road lighting luminaires, automobile lighting systems or related categories, we can provide the solutions you need.
